PRODUCTS DETAIL
정전에도 안정적인 전원 운영을 지원하는
10,000mAh 대용량 UPS
AIT-PB610
- 10,000mAh 대용량 UPS
- 정전에도 안정적인 전원 운영을 지원
- 과전류/과충전/합선 방지 및 보호
- 다양한 산업 환경에서 안전하게 활용 가능
제품 사양
- 기본 사양
- Capacity 10,000mAh (74Wh)
- Size(mm) 155* 138 * 33mm
- Weight(g) About 686g
- Battery type Lithium-ion Battery INR
18650-2500mAh 2S4P - Input DC:12V/2A (MAX)
- Output DC: 6V 2.5A
- Cycle times ≥ 500 times
- Charging and Discharging Support
- Circuit Protection Over-current Protection Under-voltage & Over-charging Protection Short circuit Protection
- Conversion efficiency 6V/2.5A ≥ 85%
- Full Charging time(input) DC charging : about 4 hours (need 2A adapter)
- Charging temperature range 0℃ ~ +50℃
- Discharging temperature range -10℃ ~ +60℃
- Storge temperature range 0℃ ~ 45℃, within 30 days
- Long- term Storge temperature range 0℃ ~ 45℃, within 180 days
- Storage humidity 45% ~ 85 % RH
- Long- term storge time Advise charging it if is not used within 90days
- KC certification No KC (YU102179-24001)
